Customized Modular Steel Walkway Grating Panels Low Maintenance Anti Slip Decking

Product Categories
Anping yuanhai wire mesh products Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Customized Modular Steel Walkway Grating Panels Low Maintenance Anti Slip Decking

  • 1
  • 2

Brand Name : YUANHAI

Model Number : YH-G1

Certification : ISO9001

Place of Origin : CHINA

MOQ : 50Pcs

Price : USD5-26/pc

Payment Terms : T/T,L/C

Supply Ability : 5000Pcs Per Month

Delivery Time : 5-10days

Packaging Details : 1.normally packed in pilling up ways with two pieces of square wood on both upperand bottom sides. 2.acccording to customer's requirements.

Material : Steel,Galvanized Sheet,Aluminum Mesh,Q235,ASTM A36 A1011 A569 Q235

Surface treatment : Hot Dipped Galvanized,galvanized,Hot dip Galvanized,painted,painting

Product name : Steel Grating,Galvanized,Safety grating walkway mesh concrete steel grating

Name : Steel Floor Decking

Sample : Free

Shape : Square,customized

Grade : Q235 Q345

Usage : Public Drain Area,metal building material,Concrete Construction Support

Contact Now

Customized Modular Steel Walkway Grating Panels Low Maintenance Anti Slip Decking
Product Attributes
Attribute Value
Material Steel,Galvanized Sheet,Aluminum Mesh,Q235,ASTM A36 A1011 A569 Q235
Surface treatment Hot Dipped Galvanized,galvanized,Hot dip Galvanized,painted,painting
Product name Steel Grating,Galvanized,Safety grating walkway mesh concrete steel grating
Name Steel Floor Decking
Sample Free
Shape Square,customized
Grade Q235 Q345
Usage Public Drain Area,metal building material,Concrete Construction Support
Fire-Rated Anti-Static Steel Walkway Grating for Data Centers & Utilities
Product Introduction

Our Modular Steel Grating Panels redefine industrial decking with a focus on hassle-free maintenance, superior slip resistance, and global supply chain reliability. Engineered for commercial decks, marina walkways, and industrial platforms, each panel features a serrated anti-slip surface (coefficient of friction ≥0.65) and a hot-dip galvanized finish for 50+ years of corrosion resistance. The modular design enables rapid installation anywhere in the world, supported by our network of 12 global distribution centers.

Data Sheet
Parameter Details
Material Q235B carbon steel, hot-dip galvanized (Zn layer ≥85μm, ISO 1461 compliant)
Panel Dimensions Standard: 1200x3000mm, 600x3000mm (custom sizes up to 1500x6000mm)
Anti-Slip Rating R13 (DIN 51130) / Class C (BS 7976-2) - suitable for wet/hazardous areas
Load Capacity Uniform load: 4.8 kN/m²; point load: 1.8 kN (tested to EN 1090-1)
Maintenance Interval 1x annual visual inspection (no painting/coating required)
Global Supply Lead Time 7-15 days (stocked panels); 20-25 days (custom orders)
Certifications CE, ISO 9001, ISO 14001
Production Process
  • Modular Fabrication: Panels cut to size with CNC machines, pre-drilled for universal mounting holes. Serrated anti-slip surfaces cold-formed at 3mm height (60° angle) for maximum traction.
  • Global Corrosion Protection: Hot-dip galvanization with region-specific adjustments: 275g/m² Zn for coastal areas, 350g/m² Zn+Al for industrial zones.
  • Quality Control for Global Markets: Each batch tested to local standards. Salt spray testing: 1,000 hours for standard panels; 2,000 hours for marine-grade.
Key Advantages
1. Worldwide Low-Maintenance Performance
  • Self-Cleaning Design: Open grid structure (83% open area) allows debris/water to pass through, reducing cleaning by 70%.
  • Corrosion Warranty: 20-year warranty on galvanized coating.
2. Modular Efficiency for Global Projects
  • Plug-and-Play Installation: Panels connect with universal U-clips (included), no site-specific modifications needed.
3. Cost-Effective Global Sourcing
  • Tariff-Optimized Supply: Production facilities in China, Mexico, and Poland to minimize import duties.
  • Lifecycle Cost Savings: 40% lower total cost than composite decking over 20 years.
Applications
  • Marine & Coastal: Marina docks, cruise ship decks, and coastal boardwalks (corrosion-resistant in saltwater).
  • Commercial & Hospitality: Rooftop decks, outdoor restaurant flooring, and shopping mall walkways (slip-safe in rain).
  • Industrial & Infrastructure: Oil refinery platforms, mining site walkways, and highway overpass decks (heavy-duty load capacity).
  • Emerging Markets: Off-grid community decks (low maintenance in remote areas), disaster relief temporary walkways.
FAQ
Q1: How do you ensure consistent quality across global shipments?
A: All panels are manufactured to ISO 9001, with regional quality audits (e.g., SGS for EU, Intertek for US).
Q2: What is your approach to global logistics?
A: We use 3PL partners with local customs expertise, providing DDP (Delivered Duty Paid) terms for 80+ countries.
Q3: How does the anti-slip surface perform in icy conditions?
A: The serrated design provides 30% better traction than smooth surfaces in ice.
